BF 0,3-8 M16 IC - CNC-precision universal drill chuck
diam. 8
l3=75 | d3=36 | d4=36 | d2=M 16 internal cooling supply
Price on request
RG80
Drill chuck
type
plain shank BF
entry-side
d1
8
Size of entry
d3
36
(see drawing)
d4
36
(see drawing)
l3
75
usable length
l2
-
(see drawing)
l1
-
cylindrical length
for threaded shank end mills
kind of connection
d2
16
connecting dimension
-
form/DIN
suitable Arbors for upper connection
Vc(m/min):
D(mm):
N(1/min):
Vf(mm/min):
fz(mm/z):
z:
ae(mm):
ap(mm):
q(cm2/min):
